QUADRO
400 / 800 / 1200
QUADRO 400
MA 220 x 90 mm
Item no.: 8740
Dimensions: 325 x 276 x 92 mm
Air flow rate: 400 m3/h
Connection voltage: 210 – 250 Volt
Motor connection: 220 x 90 mm
Weight: 3,0 kg
VP-dimensions: 660 x 310 x 110 mm
VP-unit: 1 piece
Plug / cable: Schuko / 195 cm
QUADRO 800
MA 220 x 90 mm
Item no.: 8780
Dimensions: 476 x 276 x 92 mm
Air flow rate: 800 m3/h
Connection voltage: 210 – 250 Volt
Motor connection: 220 x 90 mm
Weight: 6,0 kg
VP-dimensions: 660 x 310 x 110 mm
VP-unit: 1 piece
Plug / cable: Schuko / 195 cm
QUADRO 1200
MA 220 x 90 mm
Item no.: 8712
Dimensions: 575 x 276 x 92 mm
Air flow rate: 1200 m3/h
Connection voltage: 210 – 250 Volt
Motor connection: 220 x 90 mm
Weight: 6,5 kg
VP-dimensions: 660 x 310 x 110 mm
VP-unit: 1 piece
Plug / cable: Schuko / 195 cm
aira® QUADRO buy now
You are just one click away from fresh indoor air. Use our contact form to order your aira-QUADRO or to request information.
Information
Contact time / flow velocity: depending on degree of soiling 0.1-1 sec, 2 min
Max. pressure difference: at 2 m/s inflow, 100 Pa
Electrical operation: primary: 210-250 V, 50 Hz | secondary: HV approx. 5 KV, 10 watts
Power consumption: max. 10 watts, max. 3.65 KW p.a. | Standby consumption: max. 0.5 Watt
Subject to technical changes!
Downloads
aira® can be customised
The aira®-QUADRO does not fit your cooker bonnet? Customised developments and special requests are also possible on request.
